Two-stage Rotary Screw Air Compressor, GA+VSD Series Compressor

Optional models

Model	Volume ㎥/min	Pressure bar(e)	Power kw/hp	Weight (kg)	Dimension(mm)	Size of outlet
GA22+VSD-8.0 GA22+VSD-10 GA22+VSD-13	4.15 3.50 3.20	8.0 10 13	22/30	780	1300×750×1400	G1〞
GA30+VSD-8.0 GA30+VSD-10 GA30+VSD-13	6.40 4.90 4.20	8.0 10 13	30/45	980	1650×850×1650	G1 1/2〞
GA37+VSD-8.0 GA37+VSD-10 GA37+VSD-13	7.25 6.30 5.40	8.0 10 13	37/50	1080	1650×850×1650	G1 1/2〞
GA45+VSD-8.0 GA45+VSD-10 GA45+VSD-13	9.70 7.80 6.50	8.0 10 13	45/65	1550	1650×850×1650	G1 1/2〞
GA55+VSD-8.0 GA55+VSD-10 GA55+VSD-13	12.5 9.60 8.60	8.0 10 13	55/75	2180	1850×1050×1800	G2〞
GA75+VSD-8.0 GA75+VSD-10 GA75+VSD-13	16.50 12.50 11.20	8.0 10 13	75/100	2280	2050×1050×1850	G2〞
GA90+VSD-8.0 GA90+VSD-10 GA90+VSD-13	20.50 16.90 14.30	8.0 10 13	90/125	2500	2050×1050×1850	G2〞
GA90+VSD-8.0 GA90+VSD-10 GA90+VSD -13	20.50 16.90 14.30	8.0 10 13	90/125	2500	2050×1050×1850	G2〞
GA110+VSD-8.0 GA110+VSD-10 GA110+VSD-13	24.50 19.70 17.60	8.0 10 13	110/150	3360	2600×1660×1850	DN65
GA132+VSD-8.0 GA132+VSD-10 GA132+VSD-13	28.00 23.50 19.80	8.0 10 13	132/180	3450	2600×1660×2000	DN80
GA160+VSD-8.0 GA160+VSD-10 GA160+VSD-13	33.60 30.00 23.80	8.0 10 13	160/220	3850	2880×1780×2200	DN80
GA185+VSD-8.0 GA185+VSD-10 GA185+VSD -13	42.00 34.00 30.00	8.0 10 13	185/250	5000	3200×1780×2200	DN80
GA200+VSD-8.0 GA200+VSD-10 GA200+VSD-13	43.00 38.50 32.80	8.0 10 13	200/270	5890	3200×1780×2300	DN80
GA250+VSD-8.0 GA250+VSD-10 GA250+VSD-13	54.00 46.00 40.00	8.0 10 13	250/340	6800	3400×2120×2300	DN100
GA315+VSD-8.0 GA315+VSD-10 GA315+VSD -13	67.50 61.00 58.59	8.0 10 13	315/430	7800	3850×2050×2300	DN125
GA355+VSD-8.0 GA355+VSD-10 GA355+VSD -13	69.20 63.34 60.61	8.0 10 13	355/485	8600	3850×2050×2300	DN125
